Axiomtek, one of the world's leading designers and manufacturers of innovative, high performance and reliable PC-based industrial computer products, is pleased to introduce eBOX530-840-FL, a palm-size fanless embedded system designed for smart factory. When we take computing and communications in the factory, the data available from the numerous interconnected devices helps factory to boost productivity, optimize operation, and reduce cost and waste. It also improves logistics management as well controlling the use of material and stock more efficient. According to Intel research, there are 85% of existing industrial embedded devices currently unconnected to the Internet. Intel expects around 50 billion of devices will be connected to the internet in 2020. It created new opportunities by entering into IoT markets that had huge potential.
The Axiomtek eBOX530-840-FL is powered by the Intel® Atom™ dual core processor E3825 (codename: Bay Trail) with low power consumption and comes with DDR3L maximum memory capacity of up to 8 GB. The fanless embedded box PC is built with a heavy-duty aluminum extrusion with IP40 anti-dust ingress protection, giving it a high degree of structural strength and protection. Its fanless design allows for noiseless operations and lowers maintenance cost. The Intel® Bay Trail embedded system has optimized thermal design that allows it to function properly in extreme environments at temperatures ranging from -20°C to +60°C (-4°F to +140°F).
The ultra-compact eBOX530-840-FL comes with two RS-232/422/485 ports, one Gigabit Ethernet port, four USB 2.0 ports, one audio port (MIC-in/Line-out), one VDC 12V power input connector, one AT/ATX switch, and two SMA-type connector openings for antenna. VGA or HDMI is available upon request. It also has one full-size PCI Express Mini Card with mSATA supported. The power efficient fanless box system also supports Jumbo Frame (9K), PXE Remote Boot, Teaming, and wake-on-LAN (WOL) function to provide faster network connection. Last, but not least, this new robust embedded system is fully compatible with the Windows® Embedded Standard 7, Windows® Embedded Standard 8, and Linux.
Axiomtek’s eBOX530-840-FL is available for shipping. In addition, our eBOX product line consists of an extensive assortment of quality embedded systems with variety for any requirement and budget. For more product information or pricing, please contact one of our sales representatives or at info@axiomtek.com.tw. More information is available on our website at www.axiomtek.com or via Facebook, Twitter and YouTube.
Advanced Features:
- Intel® Atom™ Bay Trail-I E3825 1.33GHz dual core
- Compact design, fanless operation with full-featured I/O
- High performance 204-pin DDR3L-1333/1600 SO-DIMM max. up to 8 GB
- Supports 2 multi-COM ports, 1 GbE LAN and 1 Mini PCIe slot
- Supports one AT/ATX mode quick switch
- Supports Jumbo Frame (9k), WoL, PXE Remote Boot
