| CPU |
- Intel® Celeron® processor J1900 (up to 2.42 GHz) /N2807 (up to 2.16 GHz)
|
| Chipset |
|
| System Memory |
- 1 x 204-pin SO-DIMM DDR3L-1066/1333, up to 8GB
|
| BIOS |
|
| COM |
|
| USB |
|
| Ethernet |
- 1 x 10/100/1000 Mbps (Intel® i211AT)
|
| Display |
- 1 x VGA or 1 x HDMI
- 1 x LVDS
|
| Digital I/O |
|
| Audio |
|
| Storage |
|
| Expansion |
- 1 x Full-Size PCI Express Mini Card with mSATA supported
|
| Others |
- SMbus
- ST ST33TPM12LPC with TPM 1.2 compliant
|
| Battery |
|
| Power Input |
- DC power jack connector
- +12V DC-in only
- AT Auto Power On function supported
|
| Power Requirements |
- Intel® Celeron® J1900 @ 8GB DDR3L
Max. RMS. +12V @ 0.9A - Intel® Celeron® N2807 @ 8GB DDR3L
Max. RMS. +12V @ 0.7A
|
| Watchdog Timer |
|
| Hardware Monitoring |
|
| Operating Temperature |
- -20°C ~ +70°C (-4°F ~ 158°F)
|
| Relative Humidity |
- 10% ~ 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
