| CPU |
- LGA1151 socket 6th/7th generation Intel® Core™ i7/i5/i3, Pentium® & Celeron® processor
|
| Chipset |
|
| System Memory |
- 4 x 288-pin DDR4-2400/2133/1866 DIMM, up to 64GB
|
| BIOS |
|
| COM |
- 5 x RS-232 (Internal box header)
- 1 x RS-232/422/485
|
| USB |
- 6 x USB 3.2 Gen1x1 (5Gbps) (4 ports on rear I/O; 2 ports on internal box header)
- 7 x USB 2.0 (2 ports on rear I/O; 4 ports on internal pin-header; 1 port USB Type A connector onboard)
|
| Ethernet |
- 1 x 10/100/1000 Mbps (Intel® I219-LM, AMT)
- 1 x 10/100/1000 Mbps (Intel® I210-AT)
|
| Display |
|
| Digital I/O |
|
| Audio |
- HD Codec audio as MIC-in/Line-in/Line-out with Realtek ALC662
|
| Storage |
- 5 x SATA-600 with RAID 0/1/5/10
|
| Expansion |
- 1 x PCIe x16 slot
- 3 x PCIe x4 slot
- 3 x PCI slot
|
| Others |
|
| Battery |
|
| TPM |
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
