| CPU |
- 3rd gen Intel® Xeon® Scalable processors (TDP up to 270W)
|
| Chipset |
|
| System Memory |
- 6 x DDR4-3200 R-DIMM ECC memory, up to 384GB
|
| BIOS |
|
| COM |
- 1 x RS-232/422/485 (rear I/O)
|
| USB |
- 4 x USB 3.1 Gen1 (rear I/O)
- 2 x USB 3.1 Gen1 (internal box header)
- 6 x USB 2.0 (internal box header)
- 1 x USB 2.0 (180D TypeA)
|
| Ethernet |
- 2 x 10/100/1000 Mbps Ethernet (Intel® i210-AT)
|
| Display |
|
| Digital I/O |
|
| Audio |
- HD Codec audio as MIC-in/Line-in/Line-out/Speaker-out with audio kit AX93242 (optional)
|
| Storage |
- 6 x SATA-600 with RAID 0/1/5/10
- M.2 key M 2280 slot with PCIe x4 signal
|
| Expansion |
|
| Others |
- 1 x PS/2 keyboard and mouse
|
| Battery |
|
| TPM |
- TPM 2.0 module (optional)
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
